About this component
This Arduino Uno R3 CH340G is a budget-friendly development board based on the ATmega328P microcontroller. It uses the CH340G USB-to-serial converter chip instead of the standard communication chip.
It is fully compatible with the Arduino IDE and serves as an excellent option for prototyping robotics, home automation, and custom hardware projects.
The SMD version is particularly durable for vibration-prone applications like RC cars and automated rovers.
📋 Specifications
| Microcontroller | ATmega328P |
| USB-to-Serial Converter | CH340G |
| Operating Voltage | 5V |
| Input Voltage (Recommended) | 7-12V |
| Input Voltage (Limit) | 6-20V |
| Digital I/O Pins | 14 (6 provide PWM output) |
| Analog Input Pins | 6 |
| DC Current per I/O Pin | 40 mA |
| DC Current for 3.3V Pin | 50 mA |
| Flash Memory | 32 KB (0.5 KB used by bootloader) |
| SRAM | 2 KB |
| EEPROM | 1 KB |
| Clock Speed | 16 MHz |
🖥️ Arduino & Boards
Arduino UNO R3 CH340G compatible Development Board
Brand: Generic / OEM Compatible
SKU: UNO-R3-CH340G-SMD
₹299
₹349
14% OFF
Per piece
✅ In Stock (22 available)
🚚 Free shipping on orders above ₹999
View Cart
📦 Genuine components, quality tested
🔄 7-day return policy
💬 WhatsApp support available
